CLYT-CNC-350B
PVC Profile CNC Bead Cutting Saw

Contact us

If you are interested in cooperation, please contact us immediately, we will give you feedback as soon as possible!

86-186-6370-9391

Business Support

8618396817660

WhatsApp

Product Introduction

1、Equipment Features

☆ Designed for the precision 90° pre-cutting of PVC glazing bead profiles; suitable for high-volume, continuous production.

☆ Utilizes infrared transmission for high precision, eliminating the need for secondary adjustments.

☆ Equipped with a cutting tool monitoring system that tracks and alerts regarding tool service life.

☆ Features a wireless handheld control system and an automatic material-saving function.

☆ Comes standard with a profile marking function to facilitate correct profile selection and improve on-site utilization efficiency.


Product Details

2、Main Specifications and Technical Parameters:

Item

Technical Specifications

Item

Technical Specifications

Power Supply Voltage

380V 50Hz

Operating pressure

0.6-0.8Mpa

Motor Power

1.5KW

Motor speed

2800r/min

Air Consumption

15L/min

Saw blade specifications

 Φ350*Φ30*3.2mm

Cutting Width

Maximum 70mm

Cutting height

Maximum 80mm

Cutting Angle

 90°

Overall dimensions

8500*1200*1100mm

Weight

450kg



  3、Configuration of Key Components

Electrical Components

Brand

Notes

PLC

Panasonic

Japanese brand

Servo System

Hechuan

Domestic brand

Magnetic Scale

ELGO

German brand

Magnetic Readhead

AIGEEE

German brand

Wireless Measuring Gauge

ELGO

German brand

Guide Rail

PEK

Italian brand
